Complies with the verification regulations for medical magnetic resonance imaging (MRI) systems
Test items:
Detection range: 100 mT, 500 mT, 3T, 20T (automatic or manual)
Data output: - Bx, By, Bz (ASCII or binary, single point or array, calibrated or uncalibrated)
Temperature (uncalibrated)
Time stamp (10ms resolution) accuracy: ± 1% of reading
Resolution:
Uneven: 100 mT range: 300 μ T. 500 mT range: 500 μ T. 3 T range: 3 mT
Average: (100 samples) 100 mT range: 30 μ T. 500 mT range: 50 μ T. 3 T range: 300 μ T
Unit: T, mT, G, kG, MHz p (NMR frequency of proton)
Sampling rate:
-Immediately triggered (default): approximately 12 kHz (free running until the internal buffer is full)
Timing trigger: 0.36Hz-2.048 kHz (timer resolution at least 0.24 ‰; continuous reading at 2048 samples)
Bus triggered (via USB): up to approximately 400 Hz (until the internal buffer is full)
Bandwidth: DC to 1 kHz
